x-Vet DR Series by Knovelmed’s

x-Vet DR Series: Knovelmed’s Veterinary Digital Radiography & Fluoroscopy Solution

The x-Vet DR Series by Knovelmed delivers a complete all-in-one veterinary imaging solution combining high-frequency X-ray generation with a high-resolution flat-panel detector. Offered in capacitor bank and monoblock models, it supports radiography and real-time fluoroscopy across a broad kV range (40–125 kV) and mA settings up to 400 mA. With 216 anatomical presets, dynamic IGZO TFT scintillator panels, and pixel pitches as fine as 140 µm, clinicians benefit from superior image quality at reduced dose. Integrated generator–detector workflows, self-diagnostic error displays, and low-maintenance designs ensure reliable uptime, streamlined exams, and excellent value for diverse practice environments with powerful performance.

x-Vet DR Series by Knovelmed White background

High-Frequency X-Ray Generation

Powered by robust 32 kW and 20 kW capacitor bank or 5 kW monoblock generators, the x-Vet DR Series ensures stable, low-ripple kV output across 40–125 kV ranges for reliable veterinary imaging and diagnostics.

x-Vet DR Series by Knovelmed White background Closeup

High-Resolution Flat Panel Detector

Featuring advanced IGZO TFT panels with 3,072 × 3,072 pixels and 140 µm pixel pitch, Knovelmed’s detectors deliver exceptional modulation transfer function and detection quantum efficiency for sharp, low-dose veterinary radiographs.

Dog X-ray Captured with x-Vet DR Series by Knovelmed

Integrated Digital Radiography & Fluoroscopy

Combining radiography and real-time fluoroscopy in one system, the x-Vet DRF model offers continuous and pulsed fluoroscopic modes, anatomical stitching, and real-time image review to streamline clinical workflows and diagnostics.

x-Vet DR Series by Knovelmed features
x-Vet DR Series by Knovelmed Specs
